Andrew Paul's treadle
Date Added: 24 April 2008
Year Range: 1914 - 1920
Institution Name: dnhhl
Cat No: ◀ | 2005_078_002 | ▶
Picture No: 1734
Treadle used by watchmaker Andrew Alexander Paul, Golspie, to operate lathes etc on his work bench. The treadle was originally fixed to a platform underneath the bench but is now separate. The treadle consists of a cast iron wheel with five thick curved spokes supported on a cast iron frame. The wheel has a grooved steel rim to take a belt. It is operated by a cast iron stirrup which is pushed backwards and forwards to rotate the wheel.
Dimensions: Diameter 490mm - Height 615mm
